Komatsu Dozer D575 cutting edge 19M-72-11231/19M-72-11241/19M-72-21260

Products information
1)Material: Carbon steel or Manganese steel or boron steel
2)Surface: yellow paint or gray paint or as your request
3)Hardness: HB280-320 or HB320~360 or HB440~500
4)Technique: forging, machining, heat treatment
5) Package: strong plywood pallet
6) Application :used in a wide variety of applications across all Caterpillar,Komatsu , Shantui graders,bulldozers,loader buckets .Multiple edge models to match your applications and job site's needs .

Our aftermarket full sets of Komatsu D575 crawler dozer Cutting Edge & End Bits replacement are bolt-on GET wear parts specially designed for D575 crawler dozer buckets. The Komatsu D575 crawler dozers are widely used in mega open-pit overburden stripping, massive earthmoving, blasted rock handling, spoil heap construction & grading, large dam core filling and mine site reclamation.

We can supply various bevel design cutting edges for Komatsu D575 crawler dozers , including double bevel cutting edge,single bevel cutting edge, square edge and segmented cutting edge. Different bevel design fit different working site condition.We can also supply various end bit styles, including standard bolt-on end bit,heavy duty reinforced end bit,weld-on end bit and serrated end bit.

There are mainly 4 raw material options :

1. 30MnB Boron steel : use most, hardness is about HRC 440–500,can balance toughness and wear resistance well,it is ideal for sand, gravel and earth works.

2. C80 Carbon Steel : it is economical, hardness can reach HB280–360 after quenched and tempered, Suit for pure earthmoving and loose material handling, not fit rocky and high-impact sites.

3. NM400/NM450 alloy steel : own superior anti-scouring and wear resistance compared with boron steel, has greatly extending service life for long-term gravel, aggregate and construction debris working scenarios.

4. Mn13 high manganese steel : own work-hardening property, the surface will get harder under continuous impact. It fits occasional rock and hard impact. Not economical for pure earthmoving.

Welcome to contact us for more details ! Our aftermarket cutting edges and end bits have several material options including 30MnB boron steel, C80 high carbon steel, NM400/NM450 alloy steel and custom Mn13 manganese steel . The cutting edge styles include double bevel cutting edge,single bevel cutting edge, square edge and segmented cutting edge,and the end bit styles include standard bolt-on end bit,heavy duty reinforced end bit,weld-on end bit and serrated end bit. Normal production lead time is 25–35 working days upon receipt of deposit.

Model	Part number	Alternative number	Description
D575	19M-72-11231	19M7211231	Dozer cutting edge
D575	19M-72-11241	19M7211241	End edge
D575	19M-72-21260	19M7221260	End edge
D575	19M-72-13220	19M7213220	Hot cup end bit
D575	19M-72-13210	19M7213210	Hot cup end bit
D575	19M-72-11220	19M7211220	Hot cup end bit
D575	19M-72-11210	19M7211210	Hot cup end bit
