Products information 1)Material: Carbon steel or Manganese steel or boron steel 2)Surface: yellow paint or gray paint or as your request 3)Hardness: HB280-500 or HB320~360 or HB440~500 4)Technique: forging, machining, heat treatment 5) Package: strong plywood pallet 6) Application :used in a wide variety of applications across all Caterpillar,Komatsu , Shantui graders,bulldozers,loader buckets .Multiple edge models to match your applications and job site's needs .
Long wear parts product line includes a comprehensive array of cutting edges & end bits compatible with all makes and models of bulldozers .Long wear parts offer a diverse array of blade types including Boron steel dozer Cutting Edge,Manganese dozer Cutting Edge,Carbon steel dozer Cutting Edge,Boron steel dozer End Bit,Manganese dozer End Bit,Carbon steel dozer End Bit .
Part number
Alternative number
Description
Dimension
Hole
7T4341
7T-4341
Wide Center (Offset Holes)
1.625 x 16.000 x 35.500
6
7T4336
7T-4336
Wide LH End (Offset Holes)
1.625 x 16.000 x 23.125
4
7T4337
7T-4337
Wide RH End (Offset Holes)
1.625 x 16.000 x 23.125
4
7T4095
7T-4095
End Bit (Long Side) RH
2.000 x 18.500 x 24.750
7
7T4094
7T-4094
End Bit (Long Side) LH
2.000 x 18.500 x 24.750
7
8E9227
8E-9227
Dozer Blade Support
1.500 x 10.000 x 89.250
15
8E9228
8E-9228
Dozer Blade/End Bit Support
1.500 x 10.000 x 53.436
12
4T6389
4T-6389
Level Cut End Bit LH/RH
1.125 x 13.000 x 23.125
5
4T6385
4T-6385
End
1.125 x 13.000 x 48.125
8
9W4502
9W-4502
Heavier End
1.375 x 13.000 x 48.125
8
7T9782
7T-9782
Center
1.375 x 16.000 x 35.750
6
7T9779
7T-9779
End
1.375 x 16.000 x 32.750
5
9W4508
9W-4508
Heavy Duty End
1.625 x 13.000 x 48.125
8
9W3928
9W-3928
Extra Heavy Duty Center
1.750 x 16.000 x 35.750
6
9W3930
9W-3930
Extra Heavy Duty End
1.750 x 16.000 x 32.750
5
1U1545
1U-1545
Hot Cup End Bit RH
1.625 x 14.500 x 27.000
7
1U1546
1U-1546
Hot Cup End Bit LH
1.625 x 14.500 x 27.000
7
3G7763
3G-7763
Level Cut End Bit RH
1.375 x 12.750 x 24.000
7
3G7764
3G-7764
Level Cut End Bit LH
1.375 x 12.750 x 24.000
7
6Y0310
6Y-0310
Wide Center (Offset Holes)
1.375 x 16.000 x 41.000
7
6Y0311
6Y-0311
Wide LH End (Offset Holes)
1.375 x 16.000 x 48.125
8
6Y0312
6Y-0312
Wide RH End (Offset Holes)
1.375 x 16.000 x 48.125
8
7T6788
7T-6788
Heavy Duty Wide RH End (Offset Holes)
1.625 x 16.000 x 48.125
8
7T6787
7T-6787
Heavy Duty Wide LH End (Offset Holes)
1.625 x 16.000 x 48.125
8
