Products information 1)Material: Carbon steel or Manganese steel or boron steel 2)Surface: yellow paint or gray paint or as your request 3)Hardness: HB280-500 or HB320~360 or HB440~500 4)Technique: forging, machining, heat treatment 5) Package: strong plywood pallet 6) Application :used in a wide variety of applications across all Caterpillar,Komatsu , Shantui graders,bulldozers,loader buckets .Multiple edge models to match your applications and job site's needs .
Long wear parts product line includes a comprehensive array of Cutting edge, Segment ,Half arrow,Spade Nose Base Edge,Protector compatible with all makes and models of Caterpillar loaders .
Long wear parts supply full range of bolt-on and weld-in blades , edge design includes Single bevel flat edge(SBF), Wide Bevel flat edge(WBF),Double bevel flat edge(DBF).
Part number
Alternative number
Description
Dimension
Hole
9W8250
9W-8250
Center
1.375 x 19.000 x 57.650
3
9W8249
9W-8249
End
1.375 x 19.000 x 43.500
4
9W8250-13
9W-8250-13
HD Center
1.625 x 19.000 x 57.625
3
9W8249-13
9W-8249-13
HD End
1.625 x 19.000 x 43.500
4
4E7616
4E-7616
Spade Nose Base Edge
2.000 x 25.787 x 148.504
27
9U4713
9U-4713
Spade Nose Base Edge Without Holes
2.000 x 28.500 x 148.500
1019350
101-9350
Center
1.500 x 19.000 x 52.375
9
1019351
101-9351
End RH
1.500 x 19.000 x 56.000
6
1019352
101-9352
End LH
1.500 x 19.000 x 56.000
6
1073540
107-3540
HD Center
2.000 x 19.000 x 52.438
9
1073543
107-3543
HD End LH
2.000 x 19.000 x 56.000
6
1073544
107-3544
HD End RH
2.000 x 19.000 x 56.000
6
1019350FHA
101-9350FHA
Half Arrow Center (Fabricated)
1.750 x 13.500 x 51.979
9
1019351FHA
101-9351FHA
HA End RH (Fabricated)
1.750 x 13.500 x 54.000
6
1019352FHA
101-9352FHA
HA End LH (Fabricated)
1.750 x 13.500 x 54.000
6
1366790
136-6790
C/IMP Center NR
9
1366793
136-6793
C/IMP Center NR RH
6
1366794
136-6794
C/IMP Center NR LH
6
1019435
101-9435
Segment
1.500 x 19.000 x 13.625
3
1019436
101-9436
Segment RH
1.500 x 19.000 x 19.000
3
1019437
101-9437
Segment LH
1.500 x 19.000 x 19.000
3
1073536
107-3536
HD Segment
1.750 x 19.000 x 13.625
3
1073537
107-3537
HD Segment RH
1.750 x 19.000 x 19.000
3
1073538
107-3538
HD Segment LH
1.750 x 19.000 x 19.000
3
1099080
109-9080
HA Segment (Cast)
2.000 x 18.827 x 13.465
3
1099081
109-9081
HA Segment RH (Cast)
2.000 x 18.827 x 13.465
3
1099082
109-9082
HA Segment LH (Cast)
2.000 x 18.827 x 13.465
3
1099080HD
109-9080HD
HD HA Segment (Cast)
2.000 x 17.785 x 13.465
3
1099081HD
109-9081HD
HD HA Segment RH (Cast)
2.000 x 17.750 x 13.465
3
1099082HD
109-9082HD
HD HA Segment LH (Cast)
2.000 x 17.750 x 13.465
3
1380865
138-0865
C/IMP Segment REV
3
1380866
138-0866
C/IMP Segment RH REV
3
1380867
138-0867
C/IMP Segment LH REV
3
7T9127
7T-9127
Base Edge Wear Plate with HA segment
1.375 x 13.000 x 32.438
5
1330821
133-0821
Spade Nose Base Edge Without Holes
2.000 x 28.500 x 148.500
1323117
132-3117
Spade Nose Base For Segments
2.000 x 25.790 x 148.500
21
1466302
146-6302
Spade Nose Base Edge
2.000 x 25.787 x 150.472
27
1366204
136-6204
Weld-On Wear Plate
1.625 x 9.250 x 20.625
1546367
154-6367
Weld-On Wear Plate
1.000 x 6.500 x 30.500
1561039
156-1039
Base Edge With Segment Holes
2.000 x 16.456 x 149.606
21
1931756
193-1756
Corner LH/RH for 2-9J9600 Protectors
1495915
149-5915
Spade Nose Base Edge
2.000 x 27.559 x 156.000
34
9W5734HA
9W-5734HA
Half Arrow Center (Cast)
1.750 x 16.000 x 12.250
3
1566388
156-6388
Stepped Spade Nose Base Edge
2.000 x 27.756 x 156.693
27
2Q7018
2Q-7018
Spade Nose Base Edge
2.500 x 27.375 x 152.000
28
