Komatsu XS-Series SYL Twin Tiger Tooth XS25WT/XS40WT/XS50WT

Products information
1) Material: Low alloy steel / Forging
2) Surface: Standard yellow or as your request
3) Hardness: 480-520 HBW
4) Impact Strength: ≥18J (at 25°C)
5) Package: packed in plywood cases
6) Application :used in Excavator buckets, Loader bucekts,Diggers,Rippers to  efficiently dig, trench, and break hard ground.

Product Description:

Long wear parts@ supply high quality Komatsu GET Parts & Komatsu XS Series Twin Tiger Tooth . Our Komatsu excavator bucket teeth use alloy steel and precision casting technology. After professional quenching and tempering heat treatment, the surface hardness reaches HRC48–55, which greatly improves wear resistance and impact resistance, effectively solving the problem of easy wear and fracture when digging rocks and hard soil.

Our aftermarket Komatsu XS Series Twin Tiger Tooth is high‑performance dual‑point digging tip under Hensley K‑MAX XS side‑pin locking GET system. Unique forked twin‑tiger profile delivers two penetration points to split and rip compacted, friable mixed materials efficiently. It offers excellent self‑sharpening performance and superior lateral impact resistance compared with single tiger tooth. This aftermarket replacement tooth fully interchanges with original XS‑series adapters for large Komatsu mining excavators and face shovels, suitable for both bucket center and corner mounting positions. Komatsu Twin Tiger Tooth are optimized for heavily compacted soil, frozen ground, heavy clay, loose fractured rock and mixed earth‑rock mining conditions. Dual‑point geometry lowers digging resistance and improves bucket fill factor. Compatible with XS50, XS70, XS85, XS115, XS145 adapters. Not recommended for continuous heavy‑impact oversized boulders.

Except Komatsu products , we can also supply you GET Parts & Wear parts for other brands , include Caterpillar(CAT) /ESCO /Sany / Hyundai/ Hitachi/ Liebherr/ Hensley /VOLVO/ Liugong/ Xugong/ MTG/JCB/H&L/Combi/ Case/John deere/Kobelco and so on .Supporting complete spare parts matching: bucket teeth, adapters, tooth pins, retainer clips, side cutters, customers can purchase matched accessories in one order to save procurement time. Each finished bucket tooth is inspected for hardness, size and appearance one by one before delivery to eliminate defective products and stabilize product quality. Supplied with matching pins and retainers–a complete kit ready for immediate installation.

We provide 6–10 months quality warranty under normal construction conditions. If fracture occurs due to production quality problems within the warranty period, we support replacement or compensation according to the agreement.

Part number Alternative number Description
XS05WT XS05UT Komatsu XS Series Twin Tiger Tooth
XS10WT XS10UT Komatsu XS Series Twin Tiger Tooth
XS15WT XS15UT Komatsu XS Series Twin Tiger Tooth
XS20WT XS20UT Komatsu XS Series Twin Tiger Tooth
XS25WT XS25UT Komatsu XS Series Twin Tiger Tooth
XS30WT XS30UT Komatsu XS Series Twin Tiger Tooth
XS40WT XS40UT Komatsu XS Series Twin Tiger Tooth
XS50WT XS50UT Komatsu XS Series Twin Tiger Tooth
XS70WT XS70UT Komatsu XS Series Twin Tiger Tooth
XS85WT XS85UT Komatsu XS Series Twin Tiger Tooth
XS115WT XS115UT Komatsu XS Series Twin Tiger Tooth
XS145WT XS145UT Komatsu XS Series Twin Tiger Tooth
