Products information 1)Material: Carbon steel or Manganese steel or boron steel 2)Surface: yellow paint or gray paint or as your request 3)Hardness: HB280-500 or HB320~360 or HB440~500 4)Technique: forging, machining, heat treatment 5) Package: strong plywood pallet 6) Application :used in a wide variety of applications across all Caterpillar,Komatsu , Shantui graders,bulldozers,loader buckets .Multiple edge models to match your applications and job site's needs .
Long wear parts product line includes a comprehensive array of Cutting edge, Segment ,Half arrow,Spade Nose Base Edge,Protector compatible with all makes and models of Caterpillar loaders .
Long wear parts supply full range of bolt-on and weld-in blades , edge design includes Single bevel flat edge(SBF), Wide Bevel flat edge(WBF),Double bevel flat edge(DBF).
Part number
Alternative number
Description
Dimension
Hole
9V6573
9V-6573
Base Edge With Segment Holes
1.250 x 11.130 x 107.740
30
5V4696
5V-4696
Base Edge For Bolt-on Edges or Teeth
1.250 x 11.125 x 107.750
18
5V1783
5V-1783
Corner 1 hole RH
1.000 x 8.000 x 8.500
1
5V1784
5V-1784
Corner 1 hole LH
1.000 x 8.000 x 8.500
1
8E5300
8E-5300
Corner 2 hole RH
2.000 x 7.996 x 9.276
2
8E5301
8E-5301
Corner 2 hole LH
2.000 x 7.996 x 9.276
2
2530062
253-0062
New Style 2 Hole Corner Protector RH
1.125 x 8.188 x 13.375
2
2530063
253-0063
New Style 2 Hole Corner Protector LH
1.125 x 8.188 x 13.375
2
1U0601
1U-0601
Center
1.180 x 14.170 x 47.650
3
4T8101
4T-8101
End
1.250 x 19.625 x 6.688
3
1321034
132-1034
HD Center
1.375 x 14.250 x 47.650
3
1321033
132-1033
HD End
1.375 x 19.625 x 6.688
3
1U0601HAN
1U-0601HAN
HA Center (Cast)
1.625 x 10.375 x 30.250
2
4T8101HA
4T-8101HA
HA End (Cast)
1.625 x 15.125 x 8.375
3
9W3492
9W-3492
C/IMP Center NR RH
1.125 x 11.000 x 47.500
3
9W3493
9W-3493
C/IMP Center NR LH
1.125 x 11.000 x 47.500
3
9W3488
9W-3488
C/IMP End NR RH
1.125 x 14.313 x 7.063
3
9W3489
9W-3489
C/IMP End NR LH
1.125 x 14.313 x 7.063
3
4T6695
4T-6695
Segment
1.000 x 11.000 x 10.437
2
1321037
132-1037
HD Segment
1.375 x 11.000 x 10.438
2
4T6695HA
4T-6695HA
HA Segment (Cast)
1.375 x 10.875 x 10.438
2
9W6747
9W-6747
Rear Wear Plate
1.000 x 10.000 x 20.750
4
9V6575
9V-6575
Base Edge With Segment Holes
1.500 x 11.811 x 119.750
30
7V1490
7V-1490
Base Edge For Bolt-on Edges or Teeth
1.500 x 11.811 x 119.375
18
4V7174FAB
4V-7174FAB
Corner 1 hole LH
1.375 x 8.787 x 9.662
1
4V7175FAB
4V-7175FAB
Corner 1 hole RH
1.375 x 8.787 x 9.662
1
8E5310
8E-5310
Corner 2 hole RH
2.000 x 8.750 x 10.750
2
8E5311
8E-5311
Corner 2 hole LH
2.000 x 8.750 x 10.750
2
2530064
253-0064
New Style 2 Hole Corner Protector RH
1.250 x 8.938 x 15.000
2
2530065
253-0065
New Style 2 Hole Corner Protector LH
1.250 x 8.938 x 15.000
2
1735426
173-5426
Old Style 2 Hole Corner Protector RH
1.250 x 8.750 x 13.000
2
1735427
173-5427
Old Style 2 Hole Corner Protector LH
1.250 x 8.750 x 13.000
2
