Products information 1)Material: Carbon steel or Manganese steel or boron steel 2)Surface: yellow paint or gray paint or as your request 3)Hardness: HB280-500 or HB320~360 or HB440~500 4)Technique: forging, machining, heat treatment 5) Package: strong plywood pallet 6) Application :used in a wide variety of applications across all Caterpillar,Komatsu , Shantui graders,bulldozers,loader buckets .Multiple edge models to match your applications and job site's needs .
Our aftermarket full sets of Caterpillar 910 and 914 Cutting Edge and End Bits replacement are bolt-on ground engaging wear components designed for Cat 910 and 914 compact wheel loader buckets. The Cat 910 and 914 loaders are widely used in municipal maintenance, building construction backfill, landscaping, aggregate stockpiling, sand and gravel handling, farm earthworks and small quarry material transfer.
Our aftermarket Caterpillar Loader cutting edges can be classified to Single piece solid cutting edge and Segmental cutting edge , and our aftermarket Caterpillar Loader end bits can be classified to Standard End Bit,Reinforced / Heavy Duty End Bit and Rock End Bit.
Our aftermarket Caterpillar Loader cutting edges can supply various bevel design, including Double Bevel Flat Edge(DBF),Single Bevel Flat Edge(SBF),Super V Bevel and Wide Bevel Flat Edge(WBF). The bevel angle determines the cutting edge's penetration capability and wear life. A sharper edge penetrates more easily but also wears down faster , end users should select based on "material density + abrasiveness."
Part number
Alternative number
Description
Dimension
Hole
5G6133
5G-6133
Base Edge With Segment
0.750 x 7.500 x 84.660
26
5G8342
5G-8342
Base Edge With Segment
0.750 x 7.500 x 93.100
28
5G3085
5G-3085
Base Edge For Bolt-on Edges
0.750 x 7.500 x 84.660
14
6S6500
6S-6500
Base Edge For Bolt-on Edges
0.750 x 7.500 x 84.660
14
5G2807
5G-2807
Corner 1 hole RH
0.750 x 5.375 x 7.125
1
5G2806
5G-2806
Corner 1 hole LH
0.750 x 5.375 x 7.125
1
4T2920
4T-2920
Center
0.750 x 10.000 x 38.000
3
4T2918
4T-2918
End
0.750 x 10.000 x 23.250
2
4T8796
4T-8796
Center
0.750 x 10.000 x 48.875
3
4T2913
4T-2913
Center
0.750 x 10.000 x 51.500
3
9W8694
9W-8694
Center
0.750 x 10.000 x 56.000
3
9W8620
9W-8620
Center
0.750 x 10.000 x 60.000
4
4T2914
4T-2914
End
0.750 x 10.000 x 17.000
2
1957137
195-7137
HD Center
1.000 x 10.000 x 47.120
4
1957134
195-7134
HD Intermediate End RH
1.000 x 10.000 x 35.678
3
1957133
195-7133
HD Intermediate End LH
1.000 x 10.000 x 50.138
4
5G8763
5G-8763
Base Edge With Segment
0.750 x 7.500 x 89.180
24
1957140
195-7140
HD Intermediate End RH
1.000 x 10.000 x 37.406
3
1957139
195-7139
HD Intermediate End LH
1.000 x 10.000 x 52.426
4
1282872
128-2872
Center Segment
0.750 x 8.000 x 12.750
2
1282873
128-2873
End Segment
0.750 x 8.000 x 10.375
2
9W9640
9W-9640
Wider Segment
0.750 x 10.000 x 12.750
2
7T8935
7T-8935
Wider Segment
0.750 x 10.000 x 10.375
2
5G2809
5G-2809
Base Edge For Bolt-on Edges
0.750 x 7.500 x 81.875
14
1957132
195-7132
HD Intermediate End RH
1.000 x 10.000 x 34.626
3
1957131
195-7131
HD Intermediate End LH
1.000 x 10.000 x 48.376
4
6S4738
6S-4738
Multi purpose dozer center
0.625 x 6.000 x 82.000
