Products information 1)Material: Carbon steel or Manganese steel or boron steel 2)Surface: yellow paint or gray paint or as your request 3)Hardness: HB280-500 or HB320~360 or HB440~500 4)Technique: forging, machining, heat treatment 5) Package: strong plywood pallet 6) Application :used in a wide variety of applications across all Caterpillar,Komatsu , Shantui graders,bulldozers,loader buckets .Multiple edge models to match your applications and job site's needs .
Long wear parts product line includes a comprehensive array of cutting edges & end bits compatible with all makes and models of bulldozers .Long wear parts offer a diverse array of blade types including Boron steel dozer Cutting Edge,Manganese dozer Cutting Edge,Carbon steel dozer Cutting Edge,Boron steel dozer End Bit,Manganese dozer End Bit,Carbon steel dozer End Bit .
Part number
Alternative number
Description
Dimension
Hole
6Y6764
6Y-6764
1 1 " Center
1.375 x 11.000 x 59.875
10
6Y6763
6Y-6763
1 1 " Center
1.375 x 11.000 x 60.250
10
3G8277X11
3G-8277X-11
1 1 " Hot Cupped End Bit RH
1.625 x 13.000 x 21.625
7
3G8278X11
3G-8278X-11
1 1 " Hot Cupped End Bit LH
1.625 x 13.000 x 21.625
7
6Y5776
6Y-5776
Wide Center (Offset Holes)
1.625 x 13.000 x 59.875
10
6Y5777
6Y-5777
Wide Center (Offset Holes)
1.625 x 13.000 x 60.250
10
3G8277EWL
3G-8277EWL
End Bit (Long Side) RH
1.625 x 15.000 x 22.500
7
3G8278EWL
3G-8278EWL
End Bit (Long Side) LH
1.625 x 15.000 x 22.500
7
4T6513
4T-6513
Center
1.000 x 10.000 x 59.875
10
4T6532
4T-6532
End
1.000 x 10.000 x 35.875
6
4T6512
4T-6512
End
1.000 x 10.000 x 36.375
6
4T2867
4T-2867
Center
1.000 x 10.000 x 80.375
13
6Y6761
6Y-6761
1 1 " Center
1.375 x 11.000 x 35.750
6
6Y6765
6Y-6765
1 1 " Center
1.375 x 11.000 x 59.875
10
6Y6762
6Y-6762
1 1 " End
1.375 x 11.000 x 36.375
6
4T6300
4T-6300
Heavy Duty Center
1.625 x 10.000 x 59.875
10
4T6296
4T-6296
Heavy Duty End
1.625 x 10.000 x 35.750
6
4T6297
4T-6297
Heavy Duty End
1.625 x 10.000 x 36.250
6
7J2972
7J-2972
Heavy Duty Center
1.625 x 10.000 x 35.750
6
7T4348
7T-4348
Wide Center (Offset Holes)
1.625 x 13.000 x 35.750
6
7T4355
7T-4355
Wide Center (Offset Holes)
1.625 x 13.000 x 59.875
10
7T4354
7T-4354
Wide End (Offset Holes)
1.750 x 13.000 x 36.375
6
1073478
107-3478
Extra Heavy Duty Center
1.750 x 10.000 x 59.875
10
1073474
107-3474
Extra Heavy Duty End
1.750 x 10.000 x 35.750
6
1073475
107-3475
Extra Heavy Duty End
1.750 x 10.000 x 36.250
6
4J8843
4J-8843
Cast End Bit RH
1.125 x 11.997 x 18.996
7
4J8844
4J-8844
Cast End Bit LH
1.125 x 11.997 x 18.996
7
4J8843HD
4J-8843HD
Cast End Bit RH
1.126 x 12.430 x 21.231
7
4J8844HD
4J-8844HD
Cast End Bit LH
1.126 x 12.430 x 21.231
7
3G8293
3G-8293
Hot Cup End Bit RH
0.875 x 13.125 x 21.625
7
3G8294
3G-8294
Hot Cup End Bit LH
0.875 x 13.125 x 21.625
7
3G8315
3G-8315
Hot Cup End Bit RH
1.250 x 11.530 x 20.910
7
3G8316
3G-8316
Hot Cup End Bit LH
1.250 x 11.530 x 20.910
7
4T6505
4T-6505
Level Cut End Bit RH
1.000 x 10.000 x 18.580
7
4T6506
4T-6506
Level Cut End Bit LH
1.000 x 10.000 x 18.580
7
