Products information 1)Material: Carbon steel or Manganese steel or boron steel 2)Surface: yellow paint or gray paint or as your request 3)Hardness: HB280-500 or HB320~360 or HB440~500 4)Technique: forging, machining, heat treatment 5) Package: strong plywood pallet 6) Application :used in a wide variety of applications across all Caterpillar,Komatsu , Shantui graders,bulldozers,loader buckets .Multiple edge models to match your applications and job site's needs .
Long wear parts product line includes a comprehensive array of cutting edges & end bits compatible with all makes and models of bulldozers .Long wear parts offer a diverse array of blade types including Boron steel dozer Cutting Edge,Manganese dozer Cutting Edge,Carbon steel dozer Cutting Edge,Boron steel dozer End Bit,Manganese dozer End Bit,Carbon steel dozer End Bit .
Part number
Alternative number
Description
Dimension
Hole
5Q8193
5Q-8193
Center
0.625 x 8.000 x 35.079
6
8E9377
8E-9377
Center
0.625 x 8.000 x 41.500
7
4T8940
4T-8940
Center
0.625 x 8.000 x 47.000
8
4T0731
4T-0731
Center
0.750 x 8.000 x 32.125
5
1U2207
1U-2207
End
0.750 x 8.000 x 37.875
6
4T3013
4T-3013
Center
0.750 x 8.000 x 39.875
7
3G6062
3G-6062
Center
0.750 x 8.000 x 41.125
7
4T6659
4T-6659
Heavy Duty Center
0.750 x 8.000 x 41.500
7
3G4282
3G-4282
Center
0.750 x 8.000 x 45.375
7
1U2211
1U-2211
Center
0.750 x 8.000 x 54.875
9
9U8057
9U-8057
End
0.750 x 8.000 x 24.688
4
4T2315
4T-2315
Center
0.750 x 8.000 x 61.250
10
3G4285
3G-4285
Level Cut End Bit LH/RH
0.750 x 8.000 x 16.750
4
8E9379
8E-9379
Level Cut End Bit RH
1.000 x 8.000 x 18.500
4
8E9378
8E-9378
Level Cut End Bit LH
1.000 x 8.000 x 18.500
4
1406787
140-6787
Hot Cup End Bit RH
0.875 x 9.625 x 21.000
4
1406788
140-6788
Hot Cup End Bit LH
0.875 x 9.625 x 21.000
4
4T5407
4T-5407
Cast End Bit RH
1.000 x 10.000 x 21.000
4
4T5408
4T-5408
Cast End Bit LH
1.000 x 10.000 x 21.000
4
4T2983
4T-2983
Center
0.625 x 8.000 x 15.000
3
4T2972
4T-2972
End
0.625 x 8.000 x 26.500
4
4T3027
4T-3027
Heavy Duty Center
0.750 x 8.000 x 15.000
3
4T3028
4T-3028
Heavy Duty End
0.750 x 8.000 x 26.500
4
4T3025
4T-3025
Center
0.750 x 8.000 x 43.875
7
4T3026
4T-3026
End
0.750 x 8.000 x 21.875
4
4T3024
4T-3024
Center
0.750 x 8.000 x 110.875
28
4T3051
4T-3051
Level Cut End Bit RH
0.750 x 8.000 x 13.250
6
4T3052
4T-3052
Level Cut End Bit LH
0.750 x 8.000 x 13.250
6
3G8321
3G-8321
Hot Cup End Bit RH
1.000 x 10.000 x 17.500
6
3G8322
3G-8322
Hot Cup End Bit LH
1.000 x 10.000 x 17.500
6
