Products information 1)Material: Carbon steel or Manganese steel or boron steel 2)Surface: yellow paint or gray paint or as your request 3)Hardness: HB280-500 or HB320~360 or HB440~500 4)Technique: forging, machining, heat treatment 5) Package: strong plywood pallet 6) Application :used in a wide variety of applications across all Caterpillar,Komatsu , Shantui graders,bulldozers,loader buckets .Multiple edge models to match your applications and job site's needs .
Long wear parts product line includes a comprehensive array of cutting edges & end bits compatible with all makes and models of bulldozers .Long wear parts offer a diverse array of blade types including Boron steel dozer Cutting Edge,Manganese dozer Cutting Edge,Carbon steel dozer Cutting Edge,Boron steel dozer End Bit,Manganese dozer End Bit,Carbon steel dozer End Bit .
Part number
Alternative number
Description
Dimension
Hole
4T6378
4T-6378
Center
1.125 x 13.000 x 35.500
6
6Y5540
6Y-5540
Center
1.125 x 13.000 x 31.500
5
4T6386
4T-6386
Center
1.125 x 13.000 x 41.000
7
9W6092
9W-6092
Heavy Duty Center
1.375 x 13.000 x 35.500
6
7T9125
7T-9125
Heavy Duty Center
1.375 x 13.000 x 31.500
5
9W4500
9W-4500
Heavy Duty Center
1.375 x 13.000 x 41.000
7
1359669
135-9669
Level Cut End Bit RH
5
1359670
135-9670
Level Cut End Bit LH
5
7J2980
7J-2980
Center
1.625 x 13.000 x 41.000
7
9W3927
9W-3927
End
1.750 x 13.000 x 31.500
5
1122475
112-2475
End
1.750 x 13.000 x 35.500
6
8E4197
8E-4197
Cast End Bit RH
1.500 x 15.371 x 23.496
7
8E4196
8E-4196
Cast End Bit LH
1.500 x 15.371 x 23.496
7
8E4539
8E-4539
Cast End Bit RH
1.755 x 15.495 x 24.115
7
8E4540
8E-4540
Cast End Bit LH
1.755 x 15.495 x 24.115
7
8E4197HC
8E-4197HC
Hot Cup End Bit RH
2.000 x 16.000 x 24.000
7
8E4196HC
8E-4196HC
Hot Cup End Bit LH
2.000 x 16.000 x 24.000
7
8E4539HC
8E-4539HC
Hot Cup End Bit RH
2.250 x 15.472 x 23.898
7
8E4540HC
8E-4540HC
Hot Cup End Bit LH
2.250 x 15.472 x 23.898
7
1003135
100-3135
Level Cut End Bit RH
1.750 x 13.000 x 23.000
7
1003136
100-3136
Level Cut End Bit LH
1.750 x 13.000 x 23.000
7
1003137
100-3137
Level Cut End Bit RH
2.500 x 13.000 x 23.000
7
1003138
100-3138
Level Cut End Bit LH
2.500 x 13.000 x 23.000
7
1359668
135-9668
Sole Plate
2.000 x 16.000 x 41.875
7
